Stamping parts are produced in large quantities. If the stamping process can be used, the production efficiency will be greatly improved and the production cost will be reduced. Material: The material of the stamping part is Q235, carbon steel with t=1mm, which has good punching performance. Stamping parts are produced in large quantities. If the stamping process can be used, the production efficiency will be greatly improved and the production cost will be reduced.
Material: The material of the stamping part is Q235, carbon steel with t=1mm, which has good punching performance.
Stamping parts are applied to the strip, sheet, pipe and profile by means of a die and a press to cause plastic deformation or separation.
Thereby, a forming method of a workpiece (stamping) of a desired shape and size is obtained. The stamped blanks are mainly hot rolled and cold rolled steel sheets and strips.
Stamping and forging are the same plastic processing (or pressure processing), collectively called forging.
Dimensional Accuracy: All un-tolerated dimensions on the part drawing are free-size, and the workpiece dimensional tolerance can be determined according to IT14.
It can be seen from the part drawing that the dimensional accuracy of the stamping part is general, and ordinary punching can be satisfied.
Check the standard tolerance table for each dimensional tolerance:
Hole spacing:
A= mm B= mm
Part shape:
C= mm D= mm G= mm H= mm
Inside shape of the part:
E= mm F= mm
Conclusion: This stamping is suitable for general blanking.
Part structure: The stamping structure is medium and complex. The corners are all circular arc transitions. The distance between the hole and the edge of the workpiece is larger than the minimum wall thickness. The minimum aperture is Φ4mm larger than the minimum punching size Φ1mm, which is more suitable for punching. (Article extracted from: stamping parts processing, stamping parts processing manufacturers, http://) http://news.chinawj.com.cn
